FG3276 PUR Adhesives for Highly Breathable Fabric Lamination

The Advantages of Our Breathable Fabric PUR Adhesive

1. Uncompromised Moisture Permeability

Engineered with advanced molecular chain orientation technology, our PUR adhesive prevents micropore clogging. It achieves an exceptional moisture permeability of >8000 g/m²/24h (JIS L1099-B1) with a post-lamination attenuation rate of less than 5%, ensuring maximum breathability.

2. Ultra-Thin & Precision Coating

Forms a precise 0.02 mm ultra-thin adhesive layer that perfectly bridges microporous structures. This delivers robust bonding strength for waterproof membranes without adding stiffness or compromising the fabric's natural drape.

3. Extreme Weather & Aging Resistance

Built for severe environments, the cured adhesive withstands –40°C ice-water impact without brittleness (MIL-STD-810G). It also prevents hydrolysis and chalking, maintaining >95% bond retention even after 240 hours of 85°C steam aging.

4. Broad Substrate Compatibility

Provides excellent adhesion to high-density nylon (20D–500D), polyester Oxford fabric, aramid fiber, and microfiber coral fleece. It flawlessly laminates premium waterproof layers including PTFE microporous membranes (e.g., GORE-TEX®, eVent®), TPU films, and PVDF/PU coatings.

5. High Ecological Safety

100% compliant with the REACH 191 restricted substances list with zero PFOA/PFOS addition. Certified by Bluesign® and OEKO-TEX® ECO PASSPORT, ensuring maximum safety for consumer apparel.

Key Process Description

1. Heating & Melting

The PUR adhesive is heated to the recommended operational temperature, transforming into a highly flowable state optimized for thin-film or micro-dot application.

2. Micro-Dot / Slot-Die Coating

Applied precisely as a 0.02 mm layer using micro-dot roller coating or slot-die systems. This specialized application method preserves the fabric's breathable micropores while ensuring consistent coverage.

3. Low-Tension Lamination

The coated membrane is combined with the textile under controlled pressure and speed, achieving uniform wetting and immediate initial tack while preventing membrane distortion.

4. Moisture-Curing Action

The adhesive reacts with ambient moisture to form a durable, 3D cross-linked thermoset structure that resists delamination from friction, hydrostatic pressure, or repeated industrial washing.

Benefits in Outdoor & Protective Equipment

Premium Outdoor Apparel

Ideal for laminating high-end jackets and sportswear where the balance between heavy-duty weather protection (>20 kPa hydrostatic pressure, ISO 811) and wearer comfort is critical.

Extreme Environment Gear

Delivers reliable performance in military, mountaineering, and extreme-weather protective clothing, easily meeting MIL-STD-810G low-temperature requirements.

Long-Term Structural Integrity

Completely eliminates the risk of hydrolysis and chalking typical of traditional EVA or solvent-based glues upon extended water exposure.

Packing Details

Available Packaging

We have various packaging options for our PUR hot melt adhesive:

1) 200 Kg / drum, 56 drums / 20'GP

2) 20 Kg / pail or barrel, 448 pails / 20'GP

3) 2 Kg / can

4) 300 ml / cartridge

Company Information

Sino-Adhesive is a leading global manufacturer to achieve large-scale production of PUR hot melt adhesive (Polyurethane Reactive). We supply premium bonding solutions for technical textiles, highly breathable fabric lamination, waterproof garments, woodworking, and automotive interior trim.

Operating a world-class production base in Jiangmen City, Guangdong Province, China, Sino-Adhesive is certified with Bluesign, OEKO-TEX, GOTS, IATF 16949, ISO 9001, ISO 14001, and ISO 45001 systems. Welcome to contact us for customized textile bonding solutions.
